Optimisation of Stem Cell Collection for the Improvement of Eyesight Restoration Therapies: Is There a Gradient of Mesenchymal Stem Cells Along the Umbilical Cord?

Ophthalmology | Research | Sarah Moir

This summer I joined Trevor Sherwin’s lab group in the department of Ophthalmology to undertake my summer research scholarship project, funded by the University of Auckland. I was given the opportunity to investigate mesenchymal stem cells (MSC) of the human umbilical cord for the purpose of developing corneal restorative therapies. Using PCR techniques, I set out to discern a gradient of MSC concentration between the placental and foetal ends of the cord. We hope to optimise the efficiency of MSC work by distinguishing the location along the cord that yields the most MSCs. Evidently, PCR analysis produced some interesting trends.

The corneal transplant is a procedure required for distortion or damage to the stroma, a major component of the cornea.

Keratoconus is a corneal dystrophy that produces the most common need for transplant and is thus the focus of this research. However, transplants are limited by a global lack of donor tissue, where at least 55.3% of the global population lacks access to these resources [1]. While largely successful, transplant tissue efficacy deteriorates over time. Corneal graft survival occurred in 90% of patients at five years post-procedure and reduced to 82% at 10 years [1]. Studies measuring the quality of life for keratoconus patients report poor mental health as a consequence of the disorder [2]. This was attributed in part to the early onset progressive nature of the disease and anxiety around the possible need for keratoplasty. Specifically, clinical presentations of the disorder include sudden near-sightedness, astigmatism, blurred or distorted vision, sensitivity to bright light, and the need for recurrent prescriptions [3]. These outcomes reportedly leave patients with a loss of functional capacity, activity limitations, reduced participation in pleasurable activities, reduced social integration, and low self-efficacy [4]. Evidently, it would be significantly beneficial to develop a means of overcoming the accessibility and longevity limitations of current corneal restorative therapies.

The overarching goal of this research is to develop Mesenchymal Stem Cells (MSCs) as a regenerative medicine for corneal disorders. MSCs are hoped to provide an inexhaustible source of cells for eye regeneration, where they are continually replacing damaged cells and renewing the stem cell population. MSCs can be sourced from multiple sites, including the human umbilical cord. Relative to other sites, including bone marrow or adipose tissue, umbilical cord cells are less likely to develop cancerous teratomas and have higher proliferation and differentiation potential [5]. In combination with the immune-privileged nature of the cornea, stem cell transplant is a promising treatment for corneal disease.

My contribution to this research expanded on a previous Masters’ student’s work in the lab group, Vicky Wen, whose objective was to identify and quantify the distribution of MSCs along the length and within the 3-dimensional anatomy of the umbilical cord [6]. The purpose of her work was to optimise the recovery of MSCs by establishing where the greatest quantity of MSCs exist within the umbilical cord. She found evidence to suggest there is a gradient of MSCs between the foetal and placental ends of the umbilical cord. To date, no studies outside of this lab group have explored the MSC umbilical cord profile, especially their ability to differentiate into corneal keratocytes.

I received one umbilical cord (due to time and resource constraints) to perform gene expression analysis by droplet digital PCR. I dissected 1cm fragments along a 75cm umbilical cord, giving me 46 samples in total. For every 2cm of neighbouring tissue sections, 1cm was used in PCR, and 1cm was used for immuno-labelling, leaving 23 tissue samples available for each procedure.

Due to the Auckland flood and cyclone events, as well as the time waiting to retrieve the cord, the immuno-labelling portion of my project could not be completed with me present. This taught me the way research projects work sometimes, or don’t in this case, as highlighted by my supervisor.

Nevertheless, a significant portion of my project focused on learning PCR skills, where I extracted RNA from 23 umbilical cord samples to analyse for gene expression. Following DNase treatment to remove genomic DNA, I conducted RNA quality control processes, including the SPUD assay [7] to check for the presence of PCR inhibitors and the Tapestation instrument to check for the quantity and quality of RNA. After confirmation of sample quality and quantity, I synthesised cDNA from the umbilical cord RNA. The success of cDNA synthesis was checked by performing a PCR for the beta-actin gene and looking for the existence of the gene using gel electrophoresis. I continued on to learn ddPCR for gene expression analysis for my chosen genes of interest (GOI), in addition to a panel of six reference genes. The Normfinder algorithm was used to determine the most stable reference genes, and the geometric mean of the three most stable genes was used for normalisation. Normalised relative expression quantities were calculated and this allowed comparison between the 23 samples along the length of the cord [8].

Graphic pregnant women and foetus: Infographic showing stem cells of the umbilical cord. Sourced from BioRender.

My research discovered the presence of some interesting trends in MSC marker genes across the length of the umbilical cord used in my study. In particular, positive MSC markers CD90 and CD105 indicate an increase in MSC gene expression near the placental end of the cord relative to the foetal end of the cord. Positive marker CD73 shows relatively higher expression at each end of the cord; the middle section of the cord appears to have the least expression relative to the foetal end of the cord, while the placental end of the cord has a relatively similar expression to the foetal end.

Evidently, there is support for the initial hypothesis that there appears to be a pattern of MSC differentiation potential between the foetal and placental ends of the umbilical cord [6]. Our results suggest targeting the placental end of the umbilical cord will provide the most favourable yield of MSCs.

However, not all the GOI showed obvious trends of expression along the cord. These results are preliminary, as only one umbilical cord was studied. This data will thus support future grant proposals to develop this research.

Conclusions

Keratoconus exemplifies the importance of developing sustainable, successful therapies for the treatment of corneal disease. The development of effective, resourceful, and timely therapies for the treatment of keratoconus will improve the quality of life for these patients, both mentally and physically. Mesenchymal Stem Cells are a promising area of study where their optimised retrieval is an important component in supporting this wider research.

My experience in the lab was very positive and beneficial to my learning of the typical research process. I gained valuable wet lab experience, where I learnt lab etiquette and skills, including PCR and tissue sectioning/freezing. As mentioned, I learnt the way research doesn’t work sometimes (in the face of collection delays and relentless weather events), which meant I also learnt the importance of maintaining a positive attitude and persistence. All members of the Ophthalmology department were friendly, accommodating, and eager to help me if needed. I am thankful for the ongoing support and encouragement that developed my confidence and good attitude throughout my project.

I would like to express my gratitude to the University of Auckland for funding my summer research project with Trevor Sherwin’s lab group in the Ophthalmology department. I would like to thank my supervisor, Professor Sherwin, for his attention and help throughout my project. I would also like to thank Salim Ismail for his patience and guidance throughout my PCR work and Judy Loh for her encouragement and guidance throughout my immunohistochemistry work. I would also like to express my thanks to Anmol Sandhu for her help in both collecting and preparing the umbilical cord and to the donor of the cord.

Acknowledgements

[1] Liu, S., Wong, YL., & Walkden A. (2022). Current Perspectives on Corneal Transplantation. Clin Opthalmol, 2022(16), 631-646. https:// doi.org/10.2147/OPTH.S289359

[2] Kandel, H., Pesudovos, K & Watson, S. (2020). Measurement of Quality of Life in Keratoconus. Cornea, 39(3), 386-393. DOI: 10.1097/ ICO.0000000000002170

[3] Auckland Eye. (2019). Everything you need to know about keratoconus. Auckland Eye.https://www.aucklandeye.co.nz/about/blog/everythingyou-need-to-know-about-keratoconus/

[4] Cosh S, Carriere I, Nael V, Tzourio C, Delcourt C, Helmer C. (2019). The association of vision loss and dimensions of depression over 12 years in older adults: findings from the Three City study. J Affect Disord, 243, 477–484. doi:10.1016/j.jad.2018.09.071.

[5] Ziaei, M., Zhang, J., Patel, D., & McGhee, C. (2017). Umbilical cord stem cells in the treatment of corneal disease. Survey of Opthalmology, 62(6), 803-15.

[6] Wen, V. (2022). Optimising Umbilical Cord Mesenchymal Stem Cells for the Treatment of Keratoconus [Unpublished master’s thesis]. The University of Auckland

[7] Nolan, T., Hands, R. E., Ogunkolade, W., & Bustin, S. A. (2006). SPUD: A quantitative PCR assay for the detection of inhibitors in nucleic acid preparations. Analytical Biochemistry, 351(2), 308–310. https://doi. org/10.1016/j.ab.2006.01.051

[8] Andersen, C. L., Jensen, J. L., & Ørntoft, T. F. (2004). Normalization of real-time quantitative reverse transcription-PCR data: A modelbased variance estimation approach to identify genes suited for normalization, applied to bladder and colon cancer data sets. Cancer Research, 64(15), 5245–5250. https://doi.org/10.1158/0008-5472. CAN-04-0496

Sarah has just finished her third year of study at UoA as a Biology major. She is staying with Scientific as the head editor this year before she returns for postgraduate study. Having just finished her summer research project, she is off on her gap year.

Sarah Moir - BSc, Biological Sciences
